CMM Programming
CMM Programming Services
Request a quotation for part-program development.
Request a quotation
Programs Built From the Print
Part programs are built from the drawing, the CAD model, or both, and matched to the probing system installed on the machine. Datums, feature tolerances and GD&T callouts are coded directly from the controlled print, not from a prior program assumed to still be correct.
Existing programs are revised when a fixture changes, a probe is swapped, or a GD&T callout is updated on a revised print. Each revision is tested against the physical part before it replaces the version running in production.
What Is Covered
Programming support ranges from a single feature check to a full first-article inspection routine across multiple CMM software platforms.
- 01
New program development
Programs written from print and model for first-run production parts.
- 02
Program revision
Existing routines updated for tooling, probe or revision changes.
- 03
GD&T feature callouts
True position, profile and runout checks built to the print's datums.
- 04
Offline programming
Programs developed from CAD data without machine downtime.
How a Program Is Built
- 01
Print review
Features, datums and tolerances are identified from the drawing.
- 02
Fixture check
Part holding and probe access are confirmed before coding begins.
- 03
Program development
Routine written and tested against the physical part or model.
- 04
Validation run
Output reviewed against the print before final delivery.
Why Cleveland CMM Calibration and Repair
- 01
Multi-platform coding
Programs are built for the software already running on the shop floor.
- 02
Print-driven accuracy
Datums and tolerances are taken directly from the controlled drawing.
- 03
Fast revision turnaround
Updated programs follow fixture or print changes without a full rebuild.
Coverage across Northeast Ohio and the Great Lakes region
Service area covers Cleveland and surrounding Northeast Ohio communities. Confirm coverage for a specific address before scheduling.
Discuss CMM Programming Requirements
Request a quotation for a new or revised CMM program.
